25-Pin Female PCB D-Sub Connector – Precision Interface for Critical Systems
Reliable Connectivity for Industrial, Military, and Commercial Applications
SIGNALORIGIN’s 25-pin female D-sub PCB connector provides a robust and stable interface between electronic devices, ensuring reliable signal transmission in even the most demanding environments. Engineered with high-quality, durable materials, this connector supports mission-critical operations, offering excellent thermal resistance, mechanical stability, and electrical performance.
Ideal for industrial machinery, military electronics, medical systems, and computer interfaces, this PCB-mount D-sub connector delivers long-lasting reliability and ease of integration into printed circuit boards. Available in both male and female versions to support a wide range of applications and system designs.
25-Pin Female PCB D-Sub Connector – Precision Interface for Critical Systems
Reliable Connectivity for Industrial, Military, and Commercial Applications
SIGNALORIGIN’s 25-pin female D-sub PCB connector provides a robust and stable interface between electronic devices, ensuring reliable signal transmission in even the most demanding environments. Engineered with high-quality, durable materials, this connector supports mission-critical operations, offering excellent thermal resistance, mechanical stability, and electrical performance.
Ideal for industrial machinery, military electronics, medical systems, and computer interfaces, this PCB-mount D-sub connector delivers long-lasting reliability and ease of integration into printed circuit boards. Available in both male and female versions to support a wide range of applications and system designs.
| Material | Insulator material | PBT+30% G.F (UL94V-O) |
| Insulator color | Black/Blue (can be customized) | |
| Contacts material | Phosphor copper | |
| Contact plating | Gold finish over nickel | |
| Shell material | Steel/SPCC-SD, nickel or tin plated | |
| Electrical | Dielectric rating | 300V AC |
| Current rating | 5 AMP | |
| Contacts OD | ∮1.0 | |
| Contact resistance | 15mΩ Max | |
| Insulation resistance | 1000MΩ Min | |
| Mechanical | Dielectric strength | 500V AC rms at 1 minute |
| Insertion force | ∮1.0 : 0.6～2 N /Pin | |
| Extraction force | ∮1.0: 0.3 N /Pin min | |
| Durability | 500 cycles | |
| Operating temperature | -55°C to +125°C |
