The 62-pin D-sub male connector (right angle) is a cost-effective, high-density solution for compact and reliable signal transmission. Designed to meet industry-standard configurations, this connector is also available in 15, 26, 44, and 78 positions, making it ideal for space-saving applications where panel size is fixed but signal demand is high.
Engineered for mission-critical and data-intensive environments, this right-angle D-sub connector delivers long-lasting performance, mechanical durability, and stable signal integrityunder physical stress. It is widely used in telecommunications, industrial automation, military electronics, and embedded systems.
The 62-pin D-sub male connector (right angle) is a cost-effective, high-density solution for compact and reliable signal transmission. Designed to meet industry-standard configurations, this connector is also available in 15, 26, 44, and 78 positions, making it ideal for space-saving applications where panel size is fixed but signal demand is high.
Engineered for mission-critical and data-intensive environments, this right-angle D-sub connector delivers long-lasting performance, mechanical durability, and stable signal integrityunder physical stress. It is widely used in telecommunications, industrial automation, military electronics, and embedded systems.
| Material | Insulator material | PBT+30% G.F (UL94V-O) |
| Insulator color | Black/Blue (can be customized) | |
| Contacts material | Copper alloy | |
| Contact plating | Gold finish over nickel | |
| Shell material | Steel/SPCC-SD, nickel or tin plated | |
| Electrical | Dielectric rating | 300V AC |
| Current rating | 3 AMP | |
| Contacts OD | ∮0.76 | |
| Contact resistance | 15mΩ Max | |
| Insulation resistance | 1000MΩ Min at 500V DC | |
| Mechanical | Dielectric strength | 750V AC rms at 1 minute |
| Insertion force | ∮0.76: 0.3～2N /Pin | |
| Extraction force | ∮0.76: 02 N /Pin min | |
| Durability | 500 cycles | |
| Operating temperature | -55°C to +105°C |
