Our 44-pin male high-density D-sub connectors are engineered for reliability and performance in space-constrained applications. Featuring machined contacts with gold over nickel plating, 6.0mm copper alloy fork terminals, and durable nickel or tin-plated steel shells, these connectors ensure stable electrical connections and corrosion resistance. Each unit comes with nuts and high-quality insulators for secure installation and long-term durability.
Available in 15, 26, 44, 62, and 78 positions, our high-density D-sub connectors meet both RoHS and non-RoHS compliance requirements, making them suitable for a wide range of industries, including industrial automation, telecommunications, medical devices, and military-grade electronics. Standard and high-density configurations are offered to meet diverse design needs.
Our 44-pin male high-density D-sub connectors are engineered for reliability and performance in space-constrained applications. Featuring machined contacts with gold over nickel plating, 6.0mm copper alloy fork terminals, and durable nickel or tin-plated steel shells, these connectors ensure stable electrical connections and corrosion resistance. Each unit comes with nuts and high-quality insulators for secure installation and long-term durability.
Available in 15, 26, 44, 62, and 78 positions, our high-density D-sub connectors meet both RoHS and non-RoHS compliance requirements, making them suitable for a wide range of industries, including industrial automation, telecommunications, medical devices, and military-grade electronics. Standard and high-density configurations are offered to meet diverse design needs.
| Material | Insulator material | PBT+30% G.F (UL94V-O) |
| Insulator color | Black/Blue (can be customized) | |
| Contacts material | Copper alloy | |
| Contact plating | Gold finish over nickel | |
| Shell material | Steel/SPCC-SD, nickel or tin plated | |
| Electrical | Dielectric rating | 300V AC |
| Current rating | 3 AMP | |
| Contacts OD | ∮0.76 | |
| Contact resistance | 15mΩ Max | |
| Insulation resistance | 1000MΩ Min at 500V DC | |
| Mechanical | Dielectric withstanding voltage | 750V AC rms at 1 minute |
| Insertion force | ∮0.76: 0.3～2N /Pin | |
| Extraction force | ∮0.76: 02 N /Pin min | |
| Durability | 500 cycles | |
| Operating temperature | -55°C to +105°C |
