The 3w3 Male Combo D-Sub High Current Connector From Signalorigin Is Engineered For Demanding Power Applications, Offering A Robust Steel Shell With Tin Or Nickel Plating, High-Temperature White Thermoplastic Insulation, And Precision-Machined Contacts. These Contacts Deliver Enhanced Current Carrying Capacity, Improved Mechanical Strength, And A Wide Range Of Plating And Contact Configuration Options, Making Them Ideal For Power Distribution, Industrial Control Systems, Telecom Equipment, And Defense Applications.
To Meet Diverse Customer Requirements, This Connector Is Available In Multiple Performance Levels, Including Both Rohs And Non-Rohs Compliant Versions, Ensuring A Balance Of Cost And Performance. For A Complete Solution, Pair With The Matching 3w3 Female D-Sub Connector From Signalorigin.
The 3w3 Male Combo D-Sub High Current Connector From Signalorigin Is Engineered For Demanding Power Applications, Offering A Robust Steel Shell With Tin Or Nickel Plating, High-Temperature White Thermoplastic Insulation, And Precision-Machined Contacts. These Contacts Deliver Enhanced Current Carrying Capacity, Improved Mechanical Strength, And A Wide Range Of Plating And Contact Configuration Options, Making Them Ideal For Power Distribution, Industrial Control Systems, Telecom Equipment, And Defense Applications.
To Meet Diverse Customer Requirements, This Connector Is Available In Multiple Performance Levels, Including Both Rohs And Non-Rohs Compliant Versions, Ensuring A Balance Of Cost And Performance. For A Complete Solution, Pair With The Matching 3w3 Female D-Sub Connector From Signalorigin.
| Material | Insulator material | PBT thermoplastic, 30% Glass filled, UL 94V-O rated |
| Insulator color | Black/Blue (can be customized) | |
| Contacts material | Copper alloy | |
| Contact plating | Gold finish over nickel | |
| Shell material | Steel or copper alloy material, Tin/Ni or Au finished | |
| Electrical | High power contact current rating | 10, 20, 30, 40 A (can be customized) |
| The working voltage | 300V | |
| High power contact resistance | 2.7 milliohms max | |
| Contact resistance | 15mΩ Max | |
| Insulation resistance | 2000 megaohms min | |
| Mechanical | Dielectric withstanding voltage | 1000 v AC for 1 minute |
| Insertion force | ∮3.6:2～7 N /Pin | |
| Extraction force | ∮3.6:0.5 N /Pin MIN | |
| Durability | 500 cycles | |
| Operating temperature | -55°C to +125°C |
